FLATNESS TESTING USING ROBOT
The Flatness Testing Using Robot system is a high-technology system in automated quality control. This is an advanced installation that combines the automation of the flatness checking procedure of component parts that require stringent dimensions. The system is prevalent in such sectors of industries as automotive, aerospace, die and mold, precision engineering where accuracy and consistency matter the most.
This robot test system is useful because it can allow repeatable, non-contact or contact-based measurements using laser sensors, LVDTs, or digital dial gauges as well. The robotic arm is programmed to move in several test points on the component surface, removing errors of the man and operator fatigue besides vastly reducing cycle time and reliability.
Product Description
The automation also increases productivity in the sense
that
it facilitates a smooth collection and linkage of data with SCADA or
MES, or other quality monitoring systems. It facilitates 24/7
production
and it is suitable in high volume production lines. Flexibility in
testing different component sizes and geometries is possible with
custom
fixtures and modular programming with minimum change over time.
Robotic flatness testing is the most accurate, real time testing
method
coupled with scalability to those manufacturers that want to
streamline
their inspection process without necessarily depending on human
factor,
or inspection anomalies.
Additional information
- Complete robotic inspection of flatness with arm
- Removes hand handling and man-error
- Fast and precise measurements
- Combines with laser, LVDT, or digital dial gauge sensors
- Multi-point inspection backed by repeatable accuracy
- Online data logging and system unity (SCADA/MES)
- Adjustable tooling and robot path to various parts
- Applicable in a high volume production environment
- Lessens the cycle time and enhances the throughput
